Why 2226 Air Operated Grease Pump ?
The air operated grease pump with 70:1 pressure ratio are easily mount on 16 Kg standard grease bucket and are easily transportable. Ideal for long distance high pressure lubrication. Hydraulic hose is used, Piston diameter is Ø 75 mm. Through follower plate and spring pressing the grease in the reservoir is compressed and the pump feed is more easily in high viscosity greases and cold areas also. Hose and gun can be used more easily through the Z joint at the entrance of the grease gun, minimum working pressure is 6 bar maximum working pressure is 8 bar. It is recommended that you use filtered and lubricated air to optimize the performance and life of air operated grease pump. Functionalized with optional accessories .The product shipped without the bucket.
Technical Details
 | |||
| Model | 2226 | ||
| Working Type | Air | ||
| Working Pressure | 6 – 8 Bar | ||
| Pressure Ratio | 70:1 | ||
| Output | 1100 Gr/Min | ||
| Capacity | 16 Kg | ||
| Hose Length | 2 Mt | ||
| Hose Dimension | R2 1/4″ | ||
| Box Dimensions | 40x40x93 Cm | ||
| Weight | 15,6 Kg | ||
| Warranty Period | 36 Month | ||
Delivery Content
